Solutions for Non-Terminated Cables
Traditionally throughout industry when multiple cables need to be installed into one assembly, with high protection levels, a manufacturer would have to drill multiple holes and install the cables through individual cable glands. AerosUSA has designed an economical solution for installing multiple non-terminated cables with various diameters. Our line of cable plates has been designed to accommodate a variety of cable entries with the added protection of a double membrane system. The double membrane design allows for added strain relief and increased protection up to NEMA 4X and IP 66 in most models. Other key advantages of AeroUSA’s cable plates are:
- Able to accept between 4 and 72 cables in one plate.
- Wide range of cable diameters accepted in the same cable plate.
- High water and dust ingress protection, NEMA 4X / IP 66.
- UL94-V0 flammability materials are used for the ultimate in fire safety protection.
- Double membrane design for added protection and strain relief.
- Low profile options.
- Rectangular, square, and circular cut-out options.
Cable Entry System (CES) Cable Plates
When trying to feed cables into pre-existing designs, sometimes the only option is a threaded hole. This has caused manufacturers and installers problems for years when there is a need for multiple cables through one opening. AerosUSA has designed round cable entry plates to meet these needs. With many of the same great features as our square and rectangular options, the round cable entry plates offer the ability to be threaded into an application. Other key advantages are:
- Available with threads ranging from M20 to M63.
- Able to accept between 1 and 35 cables into one plate.
- Wide range of cable diameters accepted in the same cable plate.
